और अधिक उत्पाद श्रेणियाँ

LED लाइटिंग - COBs, इंजन, मॉड्यूल, स्ट्रिप्स

निर्माता भाग संख्या	उपलब्धता	मूल्य	मात्रा	डेटाशीत	Packaging	Series	ProductStatus	Type	Color	CCT(K)	Wavelength	Configuration	LuminousFlux@Current/Temperature	Current-Test	Temperature-Test	Voltage-Forward(Vf)(Typ)	Lumens/Watt@Current-Test	Current-Max	CRI(ColorRenderingIndex)	ViewingAngle	Features	Size/Dimension	Height	LightEmittingSurface(LES)
BXRH-40H1000-G-83 V6 HD NEUTRAL WHITE LED ARRAY Bridgelux	561	-	RFQ	डेटाशीत	Tube	Gen 8 V6 HD LED Array	Active	Chip On Board (COB)	White, Neutral	4000K 3-Step MacAdam Ellipse	-	Square	1395lm (Typ)	700mA	25°C	18.3V	109 lm/W	1.2A	97 (Typ)	120°	-	13.50mm L x 13.50mm W	1.63mm	6.60mm Dia
BXRH-30H1000-G-83 V6 HD WARM WHITE LED ARRAY Bridgelux	554	-	RFQ	डेटाशीत	Tube	Gen 8 V6 HD LED Array	Active	Chip On Board (COB)	White, Warm	3000K 3-Step MacAdam Ellipse	-	Square	1321lm (Typ)	700mA	25°C	18.3V	103 lm/W	1.2A	97 (Typ)	120°	-	13.50mm L x 13.50mm W	1.63mm	6.60mm Dia
BXRH-40G1000-G-83 V6 HD NEUTRAL WHITE LED ARRAY Bridgelux	505	-	RFQ	डेटाशीत	Tube	Gen 8 V6 HD LED Array	Active	Chip On Board (COB)	White, Neutral	4000K 3-Step MacAdam Ellipse	-	Square	1543lm (Typ)	700mA	25°C	18.3V	120 lm/W	1.2A	90	120°	-	13.50mm L x 13.50mm W	1.63mm	6.60mm Dia
BXRH-30G10H0-G-83 V6 HD WARM WHITE LED ARRAY Bridgelux	495	-	RFQ	डेटाशीत	Tube	Gen 8 V6 HD LED Array	Active	Chip On Board (COB)	White, Warm	3000K 3-Step MacAdam Ellipse	-	Square	1522lm (Typ)	700mA	25°C	18.3V	119 lm/W	1.2A	90	120°	-	13.50mm L x 13.50mm W	1.63mm	6.60mm Dia
BXRH-27E1000-G-83 V6 HD WARM WHITE LED ARRAY Bridgelux	485	-	RFQ	डेटाशीत	Tube	Gen 8 V6 HD LED Array	Active	Chip On Board (COB)	White, Warm	2700K 3-Step MacAdam Ellipse	-	Square	1691lm (Typ)	700mA	25°C	18.3V	132 lm/W	1.2A	80	120°	-	13.50mm L x 13.50mm W	1.63mm	6.60mm Dia
BXRH-27G10H0-B-83 V6 HD WARM WHITE LED ARRAY Bridgelux	465	-	RFQ	डेटाशीत	Tube	Gen 8 V6 HD LED Array	Active	Chip On Board (COB)	White, Warm	2700K 3-Step MacAdam Ellipse	-	Square	1448lm (Typ)	350mA	25°C	36.6V	113 lm/W	600mA	90	120°	-	13.50mm L x 13.50mm W	1.63mm	6.60mm Dia
BXRH-30H1000-B-83 V6 HD WARM WHITE LED ARRAY Bridgelux	447	-	RFQ	डेटाशीत	Tube	Gen 8 V6 HD LED Array	Active	Chip On Board (COB)	White, Warm	3000K 3-Step MacAdam Ellipse	-	Square	1321lm (Typ)	350mA	25°C	36.6V	103 lm/W	600mA	97 (Typ)	120°	-	13.50mm L x 13.50mm W	1.63mm	6.60mm Dia
BXRH-30G10H0-B-83 V6 HD WARM WHITE LED ARRAY Bridgelux	417	-	RFQ	डेटाशीत	Tube	Gen 8 V6 HD LED Array	Active	Chip On Board (COB)	White, Warm	3000K 3-Step MacAdam Ellipse	-	Square	1522lm (Typ)	350mA	25°C	36.6V	119 lm/W	600mA	90	120°	-	13.50mm L x 13.50mm W	1.63mm	6.60mm Dia
BXRH-30G1000-B-83 V6 HD WARM WHITE LED ARRAY Bridgelux	247	-	RFQ	डेटाशीत	Tube	Gen 8 V6 HD LED Array	Active	Chip On Board (COB)	White, Warm	3000K 3-Step MacAdam Ellipse	-	Square	1459lm (Typ)	350mA	25°C	36.6V	114 lm/W	600mA	90	120°	-	13.50mm L x 13.50mm W	1.63mm	6.60mm Dia
BXRH-35G1000-B-83 V6 HD WARM WHITE LED ARRAY Bridgelux	2,587	-	RFQ	डेटाशीत	Tube	Gen 8 V6 HD LED Array	Active	Chip On Board (COB)	White, Warm	3500K 3-Step MacAdam Ellipse	-	Square	1512lm (Typ)	350mA	25°C	36.6V	118 lm/W	600mA	90	120°	-	13.50mm L x 13.50mm W	1.63mm	6.60mm Dia
BXRH-30H3000-D-83 V9 HD WARM WHITE LED ARRAY Bridgelux	2,728	-	RFQ	डेटाशीत	Tube	Gen 8 V9 HD LED Array	Active	Chip On Board (COB)	White, Warm	3000K 3-Step MacAdam Ellipse	-	Square	2669lm (Typ)	700mA	25°C	36.6V	104 lm/W	1.2A	97 (Typ)	120°	-	19.00mm L x 19.00mm W	1.63mm	8.80mm Dia
BXRC-30H1000-C-83-SE VERO SE 10C WARM WHITE LED ARRAY Bridgelux	2,863	-	RFQ	डेटाशीत	Tray	Gen 8 Vero® SE 10 Array	Active	Chip On Board (COB)	White, Warm	3000K 3-Step MacAdam Ellipse	-	Round	1173lm (Typ)	300mA	25°C	30.7V	127 lm/W	1A	97 (Typ)	120°	-	30.80mm Dia	3.60mm	10.00mm Dia
BXRC-27H1000-C-83-SE VERO SE 10C WARM WHITE LED ARRAY Bridgelux	3,304	-	RFQ	डेटाशीत	Tray	Gen 8 Vero® SE 10 Array	Active	Chip On Board (COB)	White, Warm	2700K 3-Step MacAdam Ellipse	-	Round	1098lm (Typ)	300mA	25°C	30.7V	119 lm/W	1A	97 (Typ)	120°	-	30.80mm Dia	3.60mm	10.00mm Dia
BXRC-65E1001-C-84-SE VERO SE 10C COOL WHITE LED ARRAY Bridgelux	100	-	RFQ	डेटाशीत	Tray	Gen 8 Vero® SE 10 Array	Active	Chip On Board (COB)	White, Cool	6500K 4-Step MacAdam Ellipse	-	Round	1614lm (Typ)	300mA	25°C	30.7V	175 lm/W	1A	80	120°	-	30.80mm Dia	3.60mm	10.00mm Dia
BXRC-30C1001-C-84-SE VERO SE 10C WARM WHITE LED ARRAY Bridgelux	100	-	RFQ	डेटाशीत	Tray	Gen 8 Vero® SE 10 Array	Active	Chip On Board (COB)	White, Warm	3000K 4-Step MacAdam Ellipse	-	Round	1670lm (Typ)	300mA	25°C	30.7V	181 lm/W	1A	70	120°	-	30.80mm Dia	3.60mm	10.00mm Dia
BXRC-50E1001-C-84-SE VERO SE 10C COOL WHITE LED ARRAY Bridgelux	100	-	RFQ	डेटाशीत	Tray	Gen 8 Vero® SE 10 Array	Active	Chip On Board (COB)	White, Cool	5000K 4-Step MacAdam Ellipse	-	Round	1661lm (Typ)	300mA	25°C	30.7V	180 lm/W	1A	80	120°	-	30.80mm Dia	3.60mm	10.00mm Dia
BXRC-35E1000-C-83-SE VERO SE 10C WARM WHITE LED ARRAY Bridgelux	100	-	RFQ	डेटाशीत	Tray	Gen 8 Vero® SE 10 Array	Active	Chip On Board (COB)	White, Warm	3500K 3-Step MacAdam Ellipse	-	Round	1633lm (Typ)	300mA	25°C	30.7V	177 lm/W	1A	80	120°	-	30.80mm Dia	3.60mm	10.00mm Dia
BXRC-40E1000-C-83-SE VERO SE 10C NEUTRAL WHITE LED AR Bridgelux	100	-	RFQ	डेटाशीत	Tray	Gen 8 Vero® SE 10 Array	Active	Chip On Board (COB)	White, Neutral	4000K 3-Step MacAdam Ellipse	-	Round	1642lm (Typ)	300mA	25°C	30.7V	178 lm/W	1A	80	120°	-	30.80mm Dia	3.60mm	10.00mm Dia
BXRC-27E1000-C-83-SE VERO SE 10C WARM WHITE LED ARRAY Bridgelux	100	-	RFQ	डेटाशीत	Tray	Gen 8 Vero® SE 10 Array	Active	Chip On Board (COB)	White, Warm	2700K 3-Step MacAdam Ellipse	-	Round	1501lm (Typ)	300mA	25°C	30.7V	163 lm/W	1A	80	120°	-	30.80mm Dia	3.60mm	10.00mm Dia
BXRC-65C1001-C-84-SE VERO SE 10C COOL WHITE LED ARRAY Bridgelux	2,814	-	RFQ	डेटाशीत	Tray	Gen 8 Vero® SE 10 Array	Active	Chip On Board (COB)	White, Cool	6500K 4-Step MacAdam Ellipse	-	Round	1679lm (Typ)	300mA	25°C	30.7V	182 lm/W	1A	70	120°	-	30.80mm Dia	3.60mm	10.00mm Dia
