LED लाइटिंग - COBs, इंजन, मॉड्यूल, स्ट्रिप्स

निर्माता भाग संख्या	उपलब्धता	मूल्य	मात्रा	डेटाशीत	Packaging	Series	ProductStatus	Type	Color	CCT(K)	Wavelength	Configuration	LuminousFlux@Current/Temperature	Current-Test	Temperature-Test	Voltage-Forward(Vf)(Typ)	Lumens/Watt@Current-Test	Current-Max	CRI(ColorRenderingIndex)	ViewingAngle	Features	Size/Dimension	Height	LightEmittingSurface(LES)
BXRE-40E0400-B-23 LED ARRAY 400LM NEU WHITE COB Bridgelux	2,479	-	RFQ	डेटाशीत	Tray	V6 Array	Obsolete	Chip On Board (COB)	White, Neutral	4000K 3-Step MacAdam Ellipse	-	Square	426lm (Typ)	350mA	25°C	9V	135 lm/W	700mA	80	120°	-	12.50mm L x 12.50mm W	1.70mm	6.10mm Dia
BXRE-40E2000-C-23 LED ARRAY 2000LM NEU WHITE COB Bridgelux	3,366	-	RFQ	डेटाशीत	Tray	V13 Array	Obsolete	Chip On Board (COB)	White, Neutral	4000K 3-Step MacAdam Ellipse	-	Square	2262lm (Typ)	500mA	25°C	32.3V	140 lm/W	1.05A	80	120°	-	15.80mm L x 15.80mm W	1.70mm	13.40mm Dia
BXRE-40E4000-F-23 LED ARRAY 4000LM NEU WHITE COB Bridgelux	3,394	-	RFQ	डेटाशीत	Tray	V18 Array	Obsolete	Chip On Board (COB)	White, Neutral	4000K 3-Step MacAdam Ellipse	-	Square	4341lm (Typ)	1.05A	25°C	29.5V	140 lm/W	2.1A	80	120°	-	21.00mm L x 21.00mm W	1.70mm	18.60mm Dia
BXRE-40G0800-B-23 LED ARRAY 800LM NEU WHITE COB Bridgelux	2,873	-	RFQ	डेटाशीत	Tray	V8 Array	Obsolete	Chip On Board (COB)	White, Neutral	4000K 3-Step MacAdam Ellipse	-	Square	637lm (Typ)	350mA	85°C	17.4V	105 lm/W	700mA	90	120°	-	12.50mm L x 12.50mm W	1.70mm	8.10mm Dia
BXRE-40G2000-C-23 LED ARRAY 2000LM NEU WHITE COB Bridgelux	2,180	-	RFQ	डेटाशीत	Tray	V13 Array	Obsolete	Chip On Board (COB)	White, Neutral	4000K 3-Step MacAdam Ellipse	-	Square	1928lm (Typ)	500mA	25°C	32.3V	119 lm/W	1.05A	90	120°	-	15.80mm L x 15.80mm W	1.70mm	13.40mm Dia
BXRE-40G3001-D-23 LED ARRAY 3000LM NEU WHITE COB Bridgelux	2,283	-	RFQ	डेटाशीत	Tray	V15 Array	Obsolete	Chip On Board (COB)	White, Neutral	4000K 3-Step MacAdam Ellipse	-	Square	2822lm (Typ)	700mA	25°C	36V	112 lm/W	1.4A	90	120°	-	21.00mm L x 21.00mm W	1.70mm	15.20mm Dia
BXRE-40G4000-F-23 LED ARRAY 4000LM NEU WHITE COB Bridgelux	2,876	-	RFQ	डेटाशीत	Tray	V18 Array	Obsolete	Chip On Board (COB)	White, Neutral	4000K 3-Step MacAdam Ellipse	-	Square	3750lm (Typ)	1.05A	25°C	29.5V	121 lm/W	2.1A	90	120°	-	21.00mm L x 21.00mm W	1.70mm	18.60mm Dia
BXRE-40G800-A-23 LED ARRAY 800LM NEU WHITE COB Bridgelux	3,529	-	RFQ	डेटाशीत	Tray	V8 Array	Obsolete	Chip On Board (COB)	White, Neutral	4000K 3-Step MacAdam Ellipse	-	Square	637lm (Typ)	175mA	85°C	34.6V	105 lm/W	350mA	90	120°	-	12.50mm L x 12.50mm W	1.70mm	8.10mm Dia
BXRE-50C0400-A-24 LED ARRAY 400LM COOL WHITE COB Bridgelux	3,018	-	RFQ	डेटाशीत	Tray	V6 Array	Obsolete	Chip On Board (COB)	White, Cool	5000K 4-Step MacAdam Ellipse	-	Square	439lm (Typ)	175mA	25°C	18V	139 lm/W	350mA	70	120°	-	12.50mm L x 12.50mm W	1.70mm	6.10mm Dia
BXRE-50C0400-B-24 LED ARRAY 400LM COOL WHITE COB Bridgelux	2,504	-	RFQ	डेटाशीत	Tray	V6 Array	Obsolete	Chip On Board (COB)	White, Cool	5000K 4-Step MacAdam Ellipse	-	Square	439lm (Typ)	350mA	25°C	9V	139 lm/W	700mA	70	120°	-	12.50mm L x 12.50mm W	1.70mm	6.10mm Dia
BXRE-50C0800-A-24 LED ARRAY 800LM COOL WHITE COB Bridgelux	3,466	-	RFQ	डेटाशीत	Tray	V8 Array	Obsolete	Chip On Board (COB)	White, Cool	5000K 4-Step MacAdam Ellipse	-	Square	788lm (Typ)	175mA	85°C	34.6V	130 lm/W	350mA	70	120°	-	12.50mm L x 12.50mm W	1.70mm	8.10mm Dia
BXRE-50C2000-C-24 LED ARRAY 2000LM COOL WHITE COB Bridgelux	3,819	-	RFQ	डेटाशीत	Tray	V13 Array	Obsolete	Chip On Board (COB)	White, Cool	5000K 4-Step MacAdam Ellipse	-	Square	2394lm (Typ)	500mA	25°C	32.3V	148 lm/W	1.05A	70	120°	-	15.80mm L x 15.80mm W	1.70mm	13.40mm Dia
BXRE-50C3001-D-24 LED ARRAY 3000LM COOL WHITE COB Bridgelux	2,694	-	RFQ	डेटाशीत	Tray	V15 Array	Obsolete	Chip On Board (COB)	White, Cool	5000K 4-Step MacAdam Ellipse	-	Square	3654lm (Typ)	700mA	25°C	36V	145 lm/W	1.4A	70	120°	-	21.00mm L x 21.00mm W	1.70mm	15.20mm Dia
BXRE-50C4000-F-24 LED ARRAY 4000LM COOL WHITE COB Bridgelux	2,015	-	RFQ	डेटाशीत	Tray	V18 Array	Obsolete	Chip On Board (COB)	White, Cool	5000K 4-Step MacAdam Ellipse	-	Square	4603lm (Typ)	1.05A	25°C	29.5V	149 lm/W	2.1A	70	120°	-	21.00mm L x 21.00mm W	1.70mm	18.60mm Dia
BXRE-50E0400-A-24 LED ARRAY 400LM COOL WHITE COB Bridgelux	3,994	-	RFQ	डेटाशीत	Tray	V6 Array	Obsolete	Chip On Board (COB)	White, Cool	5000K 4-Step MacAdam Ellipse	-	Square	416lm (Typ)	175mA	25°C	18V	132 lm/W	350mA	80	120°	-	12.50mm L x 12.50mm W	1.70mm	6.10mm Dia
BXRE-50E0400-B-24 LED ARRAY 400LM COOL WHITE COB Bridgelux	3,922	-	RFQ	डेटाशीत	Tray	V6 Array	Obsolete	Chip On Board (COB)	White, Cool	5000K 4-Step MacAdam Ellipse	-	Square	416lm (Typ)	350mA	25°C	9V	132 lm/W	700mA	80	120°	-	12.50mm L x 12.50mm W	1.70mm	6.10mm Dia
BXRE-50E0800-A-24 LED ARRAY 800LM COOL WHITE COB Bridgelux	3,630	-	RFQ	डेटाशीत	Tray	V8 Array	Obsolete	Chip On Board (COB)	White, Cool	5000K 4-Step MacAdam Ellipse	-	Square	751lm (Typ)	175mA	85°C	34.6V	124 lm/W	350mA	80	120°	-	12.50mm L x 12.50mm W	1.70mm	8.10mm Dia
BXRE-50E0800-B-24 LED ARRAY 800LM COOL WHITE COB Bridgelux	2,383	-	RFQ	डेटाशीत	Tray	V8 Array	Obsolete	Chip On Board (COB)	White, Cool	5000K 4-Step MacAdam Ellipse	-	Square	751lm (Typ)	350mA	85°C	17.4V	123 lm/W	700mA	80	120°	-	12.50mm L x 12.50mm W	1.70mm	8.10mm Dia
BXRE-50E1000-B-24 LED ARRAY 1000LM COOL WHITE COB Bridgelux	3,025	-	RFQ	डेटाशीत	Tray	V10 Array	Obsolete	Chip On Board (COB)	White, Cool	5000K 4-Step MacAdam Ellipse	-	Square	1263lm (Typ)	350mA	25°C	26.5V	136 lm/W	700mA	80	120°	-	15.80mm L x 15.80mm W	1.70mm	9.90mm Dia
BXRE-50E2000-C-24 LED ARRAY 2000LM COOL WHITE COB Bridgelux	3,978	-	RFQ	डेटाशीत	Tray	V13 Array	Obsolete	Chip On Board (COB)	White, Cool	5000K 4-Step MacAdam Ellipse	-	Square	2252lm (Typ)	500mA	25°C	32.3V	139 lm/W	1.05A	80	120°	-	15.80mm L x 15.80mm W	1.70mm	13.40mm Dia
